Dual Head Microscope

Dual Head Microscope
Dual Head Microscope
Send Inquiry
Product Code : 25
Brand Name : Dewinter
Product Description

Backed by a team of experienced professionals, we are able to manufacture and export high quality Dual Head Microscope. The offered microscope is highly demanded in research labs and is manufactured by our experts using premium quality components and modern techniques. It is available in various technical specifications as per the varied need of the clients. Offered Dual Head Microscope is highly appreciated for its light weight, sturdy construction, durable finish standards. Also, we ensure that this microscope is checked on various quality parameters to ensure its flawless finish.



VIEWING HEAD

  • Dual viewing compensation free binocular head (55mm-75mm)

INDICATOR



  • LED cursor (Pointer)

EYEPIECE

  • Wild field Eyepieces 10X (Paired) FOV 22mm

OBJECTIVES



  • Infinity Plan Achromatic 4X
  • Infinity Plan Achromatic 10X
  • Infinity Plan Achromatic 20X
  • Infinity Plan Achromatic 40X
  • Infinity Plan Achromatic 100X

STAGE



Double layers mechanical stage



STAGE SIZE



180mmX 150mm



MOVING RANGE



70mmX50mm



CONDENSER



N.A.1.25 Abbe Condenser with iris diaphragm and filter.



FOCUSING



Coaxial coarse & fine focusing adjustment Fine focusing scale value 0.002mm



LIGHT SOURCE



Halogen bulb 6V/20W.AC 220V/110V Adjustable light source with Kohler illumination.



OPTIONAL ACCESSORY



Eyepiece: WF16X, WF20X, P16X

Objective : 20X, 60X(s)

Infinity Semi-Plan Objective: 4X, 10X, 20X, 40X(s),100X(s)Oil

Phase Contrast Attachment

Photography attachment and CCD Adapter 0.5X, 0.57X, 0.75X

Compensation Free Binocular Head (48mm-75mm)
