TRINOCULAR INVERTED MICROSCOPE

TRINOCULAR INVERTED MICROSCOPE
TRINOCULAR INVERTED MICROSCOPE
Send Inquiry
Product Code : DMI CLASSIC
Brand Name : Dewinter
Product Description

TRINOCULAR INVERTED MICROSCOPE

DEWINTER TRINOCULAR INVERTED METALLURGICAL MICROSCOPE

MODEL: DMI CLASSIC


Trinocular Observation Head

  • Siedentopf observation head inclined at 30° rotatable at 360°.

  • Vertical phototube for micro photography.

  • Diopter adjustment ring on ocular tube (±5).

  • Interpupillary distance from 52mm to 75mm.


Eyepiece (Anti fungus)

Wide field 10X (paired) F.O.V. 20mm.


Objectives (Infinity corrected)

  • M Long working distance plan 5X

  • M Long working distance plan 10X

  • M Long working distance plan 20X

  • M Long working distance plan 50X


Mechanical Body

  • Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.

  • Quadruple nosepiece on ball bearing.

  • Mechanical stage is 180mm X 155mm. Moving range 80mm X 50mm.

  • Mechanical stage has low positioned co-axial controls on ball bearing guide ways.


Illuminator

Epi-Koehler’s illumination. Aperture iris diaphragm 5W LED lamp AC 85-230V.

Adjustable brightness. Filter wheel fixed in light path with blue, green & yellow filters.


Standard Accessories

Operating manual, dust cover, guarantee card and Styrofoam molded pack.


Optional Accessories

M Long working distance plan 100x objective (dry)

Polarizer/Analyser Attachment.
